SF-LBS Analog Flexo Plates

Color Change, Removable Base

SF-LBS is a new type of analog sheet photopolymer specifically designed for Japanese and Korean corrugated market. It has the same performance as SF-L series with additional color change function, and the base can be easily removed. It provides excellent solids coverage, while its low tack and high resilience offer long and clean press runs.

Key Features
Advantage
Technical specifications

Key Features

Holds the finest detail without the need to back mask

Quick wash out

Requires minimum impression settings, giving good balance between solids and screens

Advantage

Super color contrast after main exposure

Holds the finest detail without the need to back mask

Image fidelity for high-end graphic and halftone reproduction at all gauges

Good resistance, high durability and no cupping allows for uniform impression at all process speeds

Compatible with water and alcohol-based inks containing up to 15% acetate

Suitable for corrugated post printing and other paper substrates

Technical specifications

Thickness (mm/inch)	Hardness (Shore Å)	Total Range(%)	Screen Ruling(LPI)	Minimum Isolated Line	Minimum Isolated Dot
3.94/0 .155	37	3 ‒ 90%	80	0.3mm	0.5mm
5.50/0 .217	35	3 ‒ 90%	60	0.3mm	0.5mm
7.00/0 .275	34	3 ‒ 90%	60	0.3mm	0.5mm

Recommended Processing Conditions

Thickness (mm/inch)	Back Exposure (s)	Main Exposure (mins)	Wash out (mm/mins)	Drying Time (h)	Post Exposure (mins)	Detack(mins)
3.94/0 .155	80-130	8月15日	90-110	2-2.5	5min	0
5.50/0 .217	200-300	8月18日	70-90	3	5min	0
7.00/0 .275	600-700	8月18日	70-90	3	5min	0

*Run-Length varies with its printing conditions and imaging content
