The thickness of PET can be 7mil(175μm) and 5mil（125μm）
Additional protective film prevents the black film from being scratched before ablation
High contrast, high resolution (1-99%@ 175lpi), and high optical density
Adequate ablation sensitivity, suitable for various types of CTP laser machines on the market
Use in open rooms, and suitable for post printing of corrugated plates and other paper substrates
| Size Specs | 0.635×60 Meter/roll; 1.27×30 Meter/roll; can be cut into pieces according to request |
| Thickness | 175μm/125μm |
| Material | PET polyester base |
| Min Optical Density | ≤0.03 |
| Max Optical Density | ≥4.0 |
| Laser Ablation Energy | 3.2--3.8J/cm² |
NOTE
1. The laser ablation energy depends on the types and ages of the machines. Before use, additional tests need to be done to find the
right ablation energy.
2. After removing the protective film, the film surface needs extra care to prevent scratches. Rubber gloves are suggested to use to
prevent fingerprints and scratches.
3. The suggested store conditions are placing flat in its original packaging, below 28 ℃temperature, below 70% humidity, and the shelf
life is 18 months.
*Run-Length varies with its printing conditions and imaging content
